Massarent RCCB DP-032-100 32A 100mA Double Pole Residual Current Circuit Breaker (RCCB)

Long Description

The RCCB DP-032-100 32A 100mA Double Pole Residual Current Circuit Breaker is an electrical safety device engineered to detect leakage currents and disconnect the supply automatically when unsafe conditions occur. It helps prevent electrical fires caused by insulation failure and reduces the risk of equipment damage due to earth faults.

With a 32A rated current, 100mA sensitivity, and Double Pole (DP) configuration, this RCCB disconnects both phase and neutral conductors when leakage current exceeds the defined threshold. The 100mA sensitivity is generally used for fire protection and fault monitoring in circuits where full personal protection is not the primary requirement.

Manufactured with flame-retardant thermoplastic housing and precision internal tripping mechanisms, the device ensures stable performance, low power loss, and long operational life. Its DIN rail mounting design allows easy installation in distribution boards, switchgear panels, and control systems.

The RCCB DP-032-100 is suitable for a wide range of electrical systems requiring reliable earth leakage detection and protection against electrical hazards.



Key Features

32A rated current
100mA earth leakage sensitivity
Double Pole (DP) configuration
Protection against earth faults and leakage currents
Automatic circuit disconnection
Fire hazard protection capability
DIN rail mounting design
Flame-retardant thermoplastic body
High reliability and long service life
Suitable for residential and commercial use

Applications

Residential distribution boards
Commercial electrical systems
Industrial control panels
Lighting circuits
HVAC systems
Pump and motor circuits (light duty)
Electrical switchgear
Power distribution boards
Backup power systems
Building electrical infrastructure
Fire safety protection circuits
Generator and inverter systems
Low-voltage electrical installations
Electrical maintenance systems
General fault protection circuits
