Maasarent IS0FP-125 125A Four Pole Isolator Switch

Long Description

The IS0FP-125 125A Four Pole Isolator Switch is a heavy-duty electrical isolation device engineered to safely disconnect three-phase electrical circuits along with the neutral conductor during maintenance, servicing, and inspection. Designed for manual operation, it provides complete isolation of all four poles, ensuring maximum safety for personnel and connected equipment.

Featuring a 125A rated current and a Four Pole (FP) configuration, the IS0FP-125 simultaneously disconnects all three phases and the neutral conductor, making it suitable for high-capacity electrical installations such as industrial plants, manufacturing facilities, commercial buildings, generator systems, HVAC installations, motor control centers, and power distribution networks.

Manufactured using premium flame-retardant thermoplastic housing and precision-engineered contacts, the isolator delivers excellent insulation, low contact resistance, and long mechanical and electrical life. Its compact DIN rail-mounted design enables quick installation in distribution boards, switchgear panels, and electrical control cabinets. Four-pole isolators in this class are commonly manufactured in accordance with IEC 60947-3 and DIN rail installation practices.

Key Features

125A rated current

Four Pole (FP) configuration for complete three-phase and neutral isolation

Safe manual isolation for maintenance and servicing

Quick-make, quick-break switching mechanism

Positive ON/OFF contact indication

DIN rail mounting for quick and easy installation

Compact modular design

Flame-retardant thermoplastic housing

High electrical and mechanical endurance

Finger-safe terminals for enhanced wiring safety

Suitable for residential, commercial, and industrial power distribution

Manufactured in compliance with IEC 60947-3 / IS 60947-3 standards

Applications

Three-phase distribution boards

Commercial electrical panels

Industrial control panels

Main incomer isolation

Generator distribution panels

Solar PV AC distribution boards

Electrical switchgear assemblies

Manufacturing plants

Building electrical infrastructure

Low-voltage power distribution systems

Motor control panels

Pump control panels

HVAC systems

Machinery power isolation

General-purpose three-phase electrical isolation
